Modifiedcompound PC
Qingdao Zhongxin Huamei stays at the forefront of innovation, delivering one-stop plastic solutions for 5G, new energy, wearables, healthcare, appliances, and automotive industries.
Light Diffusion PC
Performance Advantages:
1. Advantages of Light Diffusing Materials
2. Core Selling Points
3. High Light Transmittance, Haze & Diffusion
4. Visible light range: 70-90% transmittance (at 2.0 mm thickness)
5. Infrared (IR) range: ＞90% transmittance (at 2.0 mm thickness)
6. Pure Color, Good Base Tone & Customization
7. Available in different materials (PC, PMMA, PS) to meet diverse application needs; supports customized production.
8. Full-process production monitoring ensures 0 errors and consistent batch quality.
Wide Applications
1．Industry Key Products
2．Lighting Industry LED lamp shades
3．Optoelectronic Display LED display screens
4．Automotive Industry Automotive instrument panel indicator lamp shades
5．Household Products Home appliance indicator panels
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | |||
| PHYSICAL PROPERTY TABLE | |||
| ITEM | UNIT | STANDARD | TEST RESULTS |
| Density | g/cm³ | ISO 1183 | 1.102 |
| Melt Flow Rate (220°C,10kg) | g/10min | ISO 1133 | 21.5 |
| Tensile Strength | MPa | ISO 527-2 | 50 |
| Elongation At Break | % | ISO 527-2 | 12 |
| Flexural Strength | MPa | ISO 178 | 73 |
| Flexural Module | MPa | ISO 178 | 2200 |
| Charpy Notch Impact | KJ/m² | ISO 179-1 | 8 |
| Izod Notch impact | KJ/m² | ISO 180 | 9 |
| Infrared Transmittance | % | / | 92 |
