Compound Granule
Qingdao Zhongxin Huamei stays at the forefront of innovation, delivering one-stop plastic solutions for 5G, new energy, wearables, healthcare, appliances, and automotive industries.
High-temperature resistance ABS
Performance Advantages:
• Superior heat resistance
• Strong thermal stability
• Reliable processability
• Enhanced all-round performance
Typical Applications
• Air intake pipes, valve covers, radiator fan housings
• Oven control panels, coffee machine shells, induction cooker brackets
• 5G base station power module housings, server heat sink covers
• Industrial equipment parts: Printer heating unit shells, high-temperature sensor enclosures
• High-power lighting housings: LED high-bay light shells, stage lighting heat-dissipating frames
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | |||||
| PHYSICAL PROPERTY TABLE | |||||
| ITEM | UNIT | STANDARD | FR-300 | FR-330 | FR-350 |
| Vertical combustion | mm | UL94 | 1.5mm V03.0mm V0 | 1.5mm V03.0mm V0 | 1.5mm V03.0mm V0 |
| Vicat softening point | 50N 50°C/h | ISO 306 | 85 | 90 | 100 |
| Density | g/cm³ | ISO 1183 | 1.16 | 1.165 | 1.17 |
| Melt Flow Rate (220°C,10kg) | g/10min | ISO 1133 | 45 | 35 | 20 |
| Tensile Strength | MPa | ISO 527-2 | 42 | 43 | 44 |
| Elongation at break | % | ISO 527-2 | 9 | 9 | 9 |
| Flexural Strength | MPa | ISO 178 | 65 | 66 | 68 |
| Flexural Module | MPa | ISO 178 | 2200 | 2250 | 2350 |
| Izod Notch impact | J/m | ASTM D256 | 260 | 286 | 220 |
| Charpy Notch Impact | KJ/m² | ISO 179-1 | 24 | 26 | 21 |
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | |||
| PHYSICAL PROPERTY TABLE | |||
| ITEM | UNIT | STANDARD | HM-1200 |
| Vertical Flammability | / | UL94 | 1.5mmV03.0mmV0 |
| VICAT | 50N 50°C/h | ISO 306 | 84 |
| Heat Deflection Temp | 1.82MPa unannealed | ISO 75-2 | 73 |
| Heat Deflection Temp | 1.82MPa annealed | ISO 75-2 | 86 |
| Density | g/cm³ | ISO 1183 | 1.165 |
| Melt Flow Rate (220°C,10kg) | g/10min | ISO 1133 | 45 |
| Tensile Strength | MPa | ISO 527-2 | 42 |
| Elongation At Break | % | ISO 527-2 | 9 |
| Flexural Strength | MPa | ISO 178 | 65 |
| Flexural Strength | MPa | ISO 178 | 2200 |
| Notch Impact - Charpy | KJ/m³ | ISO 179-1 | 22 |
| Notch Impact - Izod | J/m | ASTM D256 | 220 |
