Raw Material
Qingdao Zhongxin Huamei, a CHIMEI joint venture and a 30+ year original factory, specializes in customizing ABS, PC, PA, PMMA and PBT plastic granules with flame-retardant, reinforced, antistatic, light-diffusing and infrared-transmitting properties. Backed by a professional R&D team, we offer free samples and technical support for global clients.
PC/ABS
Performance Advantages:
• Outstanding impact resistance: Notched impact strength of 20-30kJ/m² at -40℃, combining advantages of PC and ABS
• Improved temperature resistance: Heat distortion temperature of 100-120℃, higher than pure ABS
• Easy processing: Melt flow rate of 15-30g/10min, solving the difficulty of pure PC processing
Typical Applications: Center console frames, VR device bodies, ultrasound diagnostic device housings, bicycle helmet shells.
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | ||||
| AVERAGE GRADE | ||||
| ITEM | UNIT | PCA-308 | PCA-458 | PCA-658 |
| Melt Flow Rate (g/10min) | g/10min | 25 | 25 | 22 |
| Density (g/cm³) | g/cm³ | 1.07 | 1.1 | 1.13 |
| Tensile Strength (MPa) | MPa | 45 | 50 | 55 |
| Elongation (%) | % | 50 | 100 | 120 |
| Flexural Strength (MPa) | MPa | 70 | 75 | 78 |
| Flexural Modulus (MPa) | MPa | 2100 | 2200 | 2200 |
| Simply Supported Beam Impact (KJ/㎡) | KJ/㎡ | 35 | 40 | 45 |
| Cantilever Beam Impact (KJ/㎡) | KJ/㎡ | 40 | 45 | 50 |
| Heat Deflection Temperature (℃) | ℃ | 80 | 93 | 102 |
| Flammability Performance (/) | / | 1.5mmHB | 1.5mmHB | 1.5mmHB |
| Shrinkage (%) | % | 0.4-0.7 | 0.4-0.7 | 0.4-0.7 |
| Features | / | Impact Strength Better Than ABS | Impact Strength/Heat Resistance Better Than ABS | Balanced Mechanical Strength/Heat Resistance |
