Polybutylene Terephthalate PBT
Qingdao Zhongxinhua Mei Plastic Co., Ltd. is a professional manufacturer of engineering plastic materials. You can order high-quality polyamide 6, paraformaldehyde, polycarbonate, polybutylene terephthalate and acrylonitrile butadiene styrene at favorable prices directly from our factory.
Fire Retardant PBT Performance Advantages:
1.V0 grade flame retardant
2.1.5mm thickness meets the standard
3.extinguishes immediately upon removal from the flame.
The tracking resistance meets the 250V tracking resistance requirement.
Applications
It is applied in fields such as electronics and electrical engineering, automotive industry, communication IT, precision industry, etc., for manufacturing circuit breakers, contactors, relays, coil bobbins, BMS/OBC housings, charging guns, sensors, optical fiber connectors, server power modules, LED lamp heads, connectors, impellers, etc.
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | |||||||
| PHYSICAL PROPERTY TABLE | |||||||
| ITEM | UNIT | STANDARD | PBT GF20 | PBT GF30 | PRPBT GF20 | PRPBT GF30 | PRPBT GF30-1 |
| Tensile Strength | MPa | ISO 527-2 | 120 | 150 | 100 | 145 | 90 |
| Elongation at break | % | ISO 527-2 | - | - | - | - | - |
| Flexural Strength | MPa | ISO 178 | 180 | 220 | 170 | 215 | 180 |
| Flexural Module | MPa | ISO 178 | 6500 | 10000 | 5500 | 11500 | 9000 |
| Charpy Notch Impact | KJ/m² | ISO 179-1 | 6 | 14 | 4 | 9 | 8 |
| Lzod Notch impact | KJ/m² | ISO 180 | 7 | 15 | 6 | 10 | 8 |
| Density | g/cm³ | ISO 1183 | 1.45 | 1.55 | 1.53 | 1.62 | 1.52 |
| ASH | % | ISO 3451 | 20±1.5 | 50±1.5 | 20±2 | 30±2 | 30±2 |
| CTI | V | IEC 60112 | 250V | 250V | 250V | 250V | 400V |
| Flame retardant | / | UL-94 | HB | HB | 1.5mmV0 | 1.5mmV0 | 1.5mmV0 |
