Compound PMMA Resin
Qingdao Zhongxinhua Mei Plastic Co., Ltd. is a professional manufacturer of engineering plastic materials. You can order high-quality polyamide 6, paraformaldehyde, polycarbonate, polybutylene terephthalate and acrylonitrile butadiene styrene at favorable prices directly from our factory.
Ultra-Pure Quality: Powder content < 30 PPM | Zero black spots
Optical Excellence: Uniform color dispersion | Batch color difference < 0.3%
High Strength: Superior mechanical durability and scratch resistance
Applications: Display screens, light guide plates (LGP), signage, premium partitions, and display racks.
Supply Capacity: Factory-direct source with consistent batch stability
As a Chi Mei joint venture, we boast 30 years of rich industry experience in plastic materials manufacturing, with a strong focus on high-performance composites like Automotive PMMA for Car Lights. Our professional R&D team and advanced imported testing equipment ensure top-tier quality and technical support for products including Automotive PMMA and other engineered plastics.
As a direct manufacturer of specialty materials like Automotive PMMA, we cut out middlemen to offer you discounted pricing. Discover more details about Automotive PMMA and request free samples—click here
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | ||||
| AVERAGE GRADE | ||||
| ITEM | UNIT | CM-205 | CM-207 | CM-211 |
| Tensile Strength | MPa | 68 | 64 | 60 |
| Elongation at break | % | 10 | 7 | 7 |
| Bending elasticity | GPa | 3.2 | 3.2 | 3.2 |
| Flexural Strength | MPa | 110 | 94 | 90 |
| Rockwell strength | ASTM | M-95 | M-88 | M-84 |
| IZOD impact strength | KJ/m² | 1.8 | 1.7 | 1.6 |
| Total light transmittance | % | 92 | 92 | 92 |
| Softening point | °C | 115 | 108 | 103 |
| Heat distortion temperature | °C | 95 | 90 | 87 |
| Density | g/cm³ | 1.19 | 1.19 | 1.19 |
| Melt Flow Rate | 230°C*3.8kg cm³/10min | 2 | 9 | 17 |
| Combustion rate | UL | 1.5mmHB | 1.5mmHB | 1.5mmHB |
| Product Characteristics | / | High strength injection moldable and extrudable | medium intensity | high mobility |
What is Automotive PMMA for Car Lights?
Automotive PMMA (Polymethyl Methacrylate) is an optical-grade engineered thermoplastic specifically formulated for the automotive lighting industry. Modified to enhance ultraviolet (UV) stability, heat aging resistance, and mechanical toughness, this material delivers perfect 92% light transmittance and exceptional clarity. It is the premier choice for manufacturing car light covers, rear lamp lenses, and complex light guides, ensuring maximum durability and crystal-clear aesthetics under harsh outdoor environments.
Key Performance Advantages & Features
1. 92% Optical Transparency : Offers a high refractive index and premium surface finish, achieving 92% light transmission to eliminate light scattering and ensure maximum brightness for car headlights and tail lights.
2. Superior Weather & UV Resistance : Formulated with premium UV stabilizers, preventing yellowing, crazing, or degradation even under long-term exposure to intense sunlight and desert conditions.
3. Excellent High Heat Resistance : Engineered with high heat deflection temperatures, allowing car light housings and lenses to withstand the constant thermal load generated by high-power halogen and LED systems without warping.
4. Balanced Impact Strength : Specially modified to provide enhanced shatter and crack resistance compared to standard acrylic, protecting automotive lenses from rock chips and road debris.
5. Exceptional Injection Molding Performance: Features optimized flow and viscosity, reducing residual stress during high-speed injection molding and preventing optical defects such as weld lines or bubbles.
6. Zero-Error MES Quality Control : Backed by our Chi Mei joint venture factory's expertise, the entire modification and production process is monitored via our MES system to guarantee immaculate batch-to-batch optical consistency.
Specialized Automotive Applications
Our Automotive PMMA strictly complies with global OEM automotive standards and is widely applied across the automotive manufacturing supply chain to produce:
Exterior Lighting: Headlamp covers, tail light lenses, fog light lenses, and high-mount brake light housings.
Optical Lighting Guides: Interior ambient lighting strips, daytime running light (DRL) guides, and instrument cluster overlays.
Decorative Components: High-gloss B-pillars, rearview mirror turn signal covers, and radiator grille trim elements
As a direct manufacturer of specialty materials like Automotive PMMA, we cut out middlemen to offer you discounted pricing. Discover more details about Automotive PMMA and request free samples—click here!
