Modified PMMA Resin
Qingdao Zhongxinhua Mei Plastic Co., Ltd. is a professional manufacturer of engineering plastic materials. You can order high-quality polyamide 6, paraformaldehyde, polycarbonate, polybutylene terephthalate and acrylonitrile butadiene styrene at favorable prices directly from our factory.
PMMA Resin Light Diffusion Grade
Performance Advantages:
High light transmittance, high haze, high diffusion.
Within the visible light range (70-90% at 2.0 mm)
in the infrared region (>90% at 2.0 mm)
Color : Customization of plastic pellet color according to your requirements.
Applied to LED lamp covers, LED display screens, indicator lamp covers for car dashboards, and indicator light panels for household appliances
PS：We can provide you with free samples for evaluation and test, please feel free to contact us
Welcome to wholesale the high quality acrylic plastic granules red resin pmma material made in China from our factory. We are a 30+ year-old factory joint-ventured with Chi Mei. As one of the leading manufacturers and suppliers in China, we are equipped with advanced equipment and technology. Please be free to get the customized products from us.
PMMA-based plastic products stand out with 3 key strengths: high light transmittance, strong chemical resistance, and reliable hardness & strength.
These advantages make them widely used across scenarios:
Optical products (e.g., optical lenses)
Small containers (e.g., cosmetic bottles)
Decorative/functional items (e.g., lighting accessories)
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | ||||
| AVERAGE GRADE | ||||
| ITEM | UNIT | CM-205 | CM-207 | CM-211 |
| Tensile Strength | MPa | 68 | 64 | 60 |
| Elongation at break | % | 10 | 7 | 7 |
| Bending elasticity | GPa | 3.2 | 3.2 | 3.2 |
| Flexural Strength | MPa | 110 | 94 | 90 |
| Rockwell strength | ASTM | M-95 | M-88 | M-84 |
| IZOD impact strength | KJ/m² | 1.8 | 1.7 | 1.6 |
| Total light transmittance | % | 92 | 92 | 92 |
| Softening point | °C | 115 | 108 | 103 |
| Heat distortion temperature | °C | 95 | 90 | 87 |
| Density | g/cm³ | 1.19 | 1.19 | 1.19 |
| Melt Flow Rate | 230°C*3.8kg cm³/10min | 2 | 9 | 17 |
| Combustion rate | UL | 1.5mmHB | 1.5mmHB | 1.5mmHB |
| Product Characteristics | / | High strength injection moldable and extrudable | medium intensity | high mobility |
Qingdao Zhongxin Huamei Plastics Co., Ltd. plastic granules raw material safety stock is at least 5000 tons. Auxiliary materials and additives are fully stocked, ensuring stable, reliable supply.The color performance characteristics of our plastic granules can be customized and manufactured in accordance with your specific requirements.
PMMA, alternatively referred to as polymethyl methacrylate or acrylic, boasts the following core properties:
PMMA features exceptional transparency, with a light transmittance rate ranging from 90% to 92%—a level that surpasses that of numerous inorganic materials like ordinary glass.
We offer customized packaging solutions tailored to your specific needs.Click here to learn more about our plastic granules.
