Modifiedcompound PC
Qingdao Zhongxin Huamei stays at the forefront of innovation, delivering one-stop plastic solutions for 5G, new energy, wearables, healthcare, appliances, and automotive industries.
Infrared Transmitting PC
Performance Advantages:
1. High Infrared Transmittance
2. ≥90% transmittance in the 700nm-2000nm range; up to 93% at 940nm and 91% at 850nm (excellent IR signal penetration).
3. High Visible Light Shielding
4. Visible light transmittance <5% (effectively blocks visible light while maintaining IR performance).
5. Customizable Wavelength Control
6. Adjustable transmittance for specific R (Red)、G (Green)、B (Blue) wavelengths, meeting functional requirements for targeted scenarios.
Typical Applications
1．Smart home devices
2．Smart speakers
3．Remote controls
4．Smart game controllers
5．Lamp shades
| Physical properties table Flame retardant,heat resistant,impact resistant18 properties one-stop customization | |||
| PHYSICAL PROPERTY TABLE | |||
| ITEM | UNIT | STANDARD | TEST RESULTS |
| Density | g/cm³ | ISO 1183 | 1.102 |
| Melt Flow Rate (220°C,10kg) | g/10min | ISO 1133 | 21.5 |
| Tensile Strength | MPa | ISO 527-2 | 50 |
| Elongation At Break | % | ISO 527-2 | 12 |
| Flexural Strength | MPa | ISO 178 | 73 |
| Flexural Module | MPa | ISO 178 | 2200 |
| Charpy Notch Impact | KJ/m² | ISO 179-1 | 8 |
| Izod Notch impact | KJ/m² | ISO 180 | 9 |
| Infrared Transmittance | % | / | 92 |
